Description
SKF Double direction angular contact thrust ball bearing, super-precision
| Designation | Principal dimensions | Basic load ratings | Attainable speeds | ||||
| dynamic | static | Grease lubrication | Oil-air lubrication | ||||
| d[mm] | D[mm] | H[mm] | C[kN] | C0[kN] | [r/min] | [r/min] | |
| SKF BTW35CTN9/SP | 35 | 62 | 34 | 16.8 | 39 | 11 000 | 14 000 |
| SKF BTW40CTN9/SP | 40 | 68 | 36 | 19.5 | 46.5 | 10 000 | 13 000 |
| SKF BTW45CTN9/SP | 45 | 75 | 38 | 22.1 | 54 | 9 500 | 12 000 |
| SKF BTW50CTN9/SP | 50 | 80 | 38 | 22.5 | 60 | 9 000 | 11 000 |
| SKF BTW55CTN9/SP | 55 | 90 | 44 | 30.2 | 80 | 7 500 | 9 000 |
| SKF BTW60CTN9/SP | 60 | 95 | 44 | 30.7 | 83 | 7 500 | 9 000 |
| SKF BTW65CTN9/SP | 65 | 100 | 44 | 31.9 | 90 | 7 000 | 8 500 |
| SKF BTW70CTN9/SP | 70 | 110 | 48 | 39 | 112 | 6 700 | 8 000 |
| SKF BTW75CTN9/SP | 75 | 115 | 48 | 39.7 | 116 | 6 300 | 7 500 |
| SKF BTW80CTN9/SP | 80 | 125 | 54 | 47.5 | 140 | 5 600 | 6 700 |
| SKF BTW85CTN9/SP | 85 | 130 | 54 | 48.8 | 146 | 5 600 | 6 700 |
| SKF BTW90CTN9/SP | 90 | 140 | 60 | 55.9 | 173 | 5 000 | 6 000 |
| SKF BTW95CTN9/SP | 95 | 145 | 60 | 57.2 | 180 | 5 000 | 6 000 |
| SKF BTM 100BTN9/P4CDB | 100 | 150 | 45 | 48 | 116 | 5 600 | 7 100 |
| SKF BTW100CTN9/SP | 100 | 150 | 60 | 59.2 | 193 | 5 000 | 6 000 |
| SKF BTW110CTN9/SP | 110 | 170 | 72 | 81.9 | 260 | 4 300 | 5 000 |
| SKF BTM 120ATN9/P4CDB | 120 | 180 | 54 | 58.5 | 146 | 5 200 | 6 700 |
| SKF BTW120CTN9/SP | 120 | 180 | 72 | 85.2 | 280 | 4 000 | 4 800 |
| SKF BTM 130BTN9/HCP4CDB | 130 | 200 | 63 | 85 | 208 | 5 100 | 6 100 |
| SKF BTW130CTN9/SP | 130 | 200 | 84 | 106 | 360 | 3 600 | 4 300 |
| SKF BTW140CM/SP | 140 | 210 | 84 | 106 | 375 | 3 200 | 3 800 |
| SKF BTW150CM/SP | 150 | 225 | 90 | 127 | 440 | 3 000 | 3 600 |
| SKF BTW160CM/SP | 160 | 240 | 96 | 140 | 510 | 2 800 | 3 400 |
| SKF BTW170CM/SP | 170 | 260 | 108 | 174 | 610 | 2 400 | 3 000 |
| SKF BTW180CM/SP | 180 | 280 | 120 | 199 | 710 | 2 000 | 2 600 |
| SKF BTW190CM/SP | 190 | 290 | 120 | 203 | 735 | 2 000 | 2 600 |
| SKF BTW200CM/SP | 200 | 310 | 132 | 238 | 865 | 1 900 | 2 400 |
As a professional bearing exporter and authorized SKF® distributor, WS Bearing stocks thousands kindsof angular contact thrust ball bearing for sale，We can export to Singapore–Viet Nam–Malaysia–Indonesia-America-Germany etc. If you have problems about selecting proper bearings for your special applications, please contact us right now
